9-82
 When Fuji standard 8-series IM (P99 = 0 or A39 = 0) or other motors (P99 = 4 or A39 =
4) are selected, the motor parameters are as listed in the following tables.
200 V class series for Asia version
(FRN_ _ _ _C2S-2A, FRN_ _ _ _C2-7A)
220 V, 60 Hz, rated voltage, base frequency, Fuji standard 8-series
Motor capacity
(kW)
Rated
current
(A)
No-load
current
(A)
%R1
(%)
%X1
(%)
Rated slip
frequency
(Hz)
P02/A16
Nominal
applied
motor
(kW)
P03/A17 P06/A20 P07/A21 P08/A22 P12/A26
0.01 to 0.09 0.06 0.40 0.37 11.40 9.71 1.77
0.10 to 0.19 0.1 0.62 0.50 10.74 10.50 1.77
0.20 to 0.39 0.2 1.18 0.97 10.69 10.66 2.33
0.40 to 0.74 0.4 2.10 1.52 8.47 11.34 2.40
0.75 to 1.49 0.75 3.29 2.11 7.20 8.94 2.33
1.50 to 2.19 1.5 5.56 2.76 5.43 9.29 2.00
2.20 to 3.69 2.2 8.39 4.45 5.37 9.09 1.80
3.70 to 5.49 3.7 13.67 7.03 4.80 9.32 1.93
5.50 to 7.49 5.5 20.50 10.08 4.37 11.85 1.40
7.50 to 10.99 7.5 26.41 11.46 3.73 12.15 1.57
11.00 to 14.99 11 38.24 16.23 3.13 12.49 1.07
15.00 to 18.49 15 50.05 18.33 2.69 13.54 1.13
18.50 to 21.99 18.5 60.96 19.62 2.42 13.71 0.87
22.00 to 29.99 22 70.97 23.01 2.23 13.24 0.90
30.00 30 97.38 35.66 2.18 12.38 0.80
400 V class series for Asia version (FRN_ _ _ _C2-4A)
380 V, 60 Hz, rated voltage, base frequency, Fuji standard 8-series
Motor capacity
(kW)
Rated
current
(A)
No-load
current
(A)
%R1
(%)
%X1
(%)
Rated slip
frequency
(Hz)
P02/A16
Nominal
applied
motor
(kW)
P03/A17 P06/A20 P07/A21 P08/A22 P12/A26
0.01 to 0.09 0.06 0.19 0.16 12.54 10.68 1.77
0.10 to 0.19 0.10 0.31 0.21 12.08 11.81 1.77
0.20 to 0.39 0.20 0.58 0.42 12.16 12.14 2.33
0.40 to 0.74 0.4 1.07 0.66 9.99 13.38 2.40
0.75 to 1.49 0.75 1.72 0.91 8.72 10.82 2.33
1.50 to 2.19 1.5 3.10 1.20 6.89 11.80 2.00
2.20 to 3.69 2.2 4.54 1.92 6.73 11.40 1.80
3.70 to 5.49 3.7 7.43 3.04 6.04 11.73 1.93
5.50 to 7.49 5.5 11.49 4.35 5.55 15.05 1.40
7.50 to 10.99 7.5 14.63 4.95 4.78 15.59 1.57
11.00 to 14.99 11 21.23 7.01 4.02 16.06 1.07
15.00 to 18.49 15 28.11 7.92 3.50 17.61 1.13
18.50 to 21.99 18.5 35.01 8.47 3.16 17.97 0.87
22.00 to 29.99 22 40.11 9.98 2.92 17.32 0.90
30.00 30 55.21 15.44 2.84 16.10 0.80
A box (■) in the above inverter types replaces S (Basic type) or E (EMC filter built-in type) depending on the
enclosure.
