G.2.2 RS-485 communication support models
FVR-C11S vs. FRENIC-Mini
FVR-C11S (IP20)
with RS-485 communications card (option) mounted
(Ambient temperature: 50°C)
FRENIC-Mini (IP20)
(Ambient temperature: 50°C)
External dimensions (mm) Mounting area Volume External dimensions (mm)
Mount-
ing area
Volume
Power
supply
voltage
Applic-
able
motor
rating
(kW)
W H D D1 D2
m
2
(x10
-2
)
/Mini
(%)
m
3
(x10
-3
)
/Mini
(%)
W H D D1 D2
m
2
(x10
-2
)
m
3
(x10
-3
)
0.1 80 120 90 80 10 1.0 100.0 0.9 112.5 80 120 80 70 10 1.0 0.8
0.2 80 120 95 80 15 1.0 100.0 0.9 118.8 80 120 80 70 10 1.0 0.8
0.4 80 120 105 80 25 1.0 100.0 1.0 110.5 80 120 95 70 25 1.0 0.9
0.75 80 120 130 80 50 1.0 100.0 1.2 108.3 80 120 120 70 50 1.0 1.2
1.5 110 130 149 85 64 1.4 100.0 2.1 107.2 110 130 139 75 64 1.4 2.0
2.2 110 130 149 85 64 1.4 100.0 2.1 107.2 110 130 139 75 64 1.4 2.0
3-
phase
200 V
3.7 140 180 147 75 72 2.5 100.0 3.7 105.8 140 180 139 75 64 2.5 3.5
0.4 – – – – – – – – – 110 130 115 75 40 1.4 1.6
0.75 – – – – – – – – – 110 130 139 75 64 1.4 2.0
1.5 – – – – – – – – – 110 130 139 75 64 1.4 2.0
2.2 – – – – – – – – – 110 130 139 75 64 1.4 2.0
3-
phase
400 V
3.7 – – – – – – – – – 140 180 139 75 64 2.5 3.5
0.1 80 120 90 80 10 1.0 100.0 0.9 112.5 80 120 80 70 10 1.0 0.8
0.2 80 120 95 80 15 1.0 100.0 0.9 118.8 80 120 80 70 10 1.0 0.8
0.4 80 120 125 100 25 1.0 100.0 1.2 131.6 80 120 95 70 25 1.0 0.9
0.75 80 120 150 100 50 1.0 100.0 1.4 107.1 80 120 140 90 50 1.0 1.3
1.5 110 130 159 95 64 1.4 100.0 2.3 106.7 110 130 149 85 64 1.4 2.1
1-
phase
200 V
2.2 140 180 147 75 72 2.5 100.0 3.7 105.8 140 180 139 75 64 2.5 3.5
