Machine Components
33
Product Overview
2
îš„High Capacity Stacker (optional)
No. Component Function
1 De-curl button Fixes the curl of output copies if they are curled when they were
delivered.
2 Error lamp If a paper jam occurs, the lamp of the jammed location lights up.
3 Sample button Press this button to output a sample page onto the stacker output tray.
4 Paper eject button Press this button when removing copied outputs.
5 Stacker output tray Copied outputs are delivered here. A sample page or sample set of a
document is delivered in this tray.
6 Ground fault interrupter
(Interface module)
Automatically shuts off electricity in the event of current leakage.
7 Ground fault interrupter
(High capacity stacker)
Automatically shuts off electricity in the event of current leakage.
8 Stacker top cover Open this cover when clearing paper jams.
9 Stacker tray (Stacker cart) Copied outputs are delivered here.
10 Stacker front cover Open this cover when removing copied outputs.
11 Interface module front cover Open this cover when clearing paper jams.
1
2
3
4
11
9
5
6
7
8
10
