2 Product Overview
32
Product Overview
2
îš„High Capacity Feeder C2-DS (optional)
No. Component Function
1 Ground fault interrupter Automatically shuts off electricity in the event of current leakage.
2 Tray 5 (Bypass) Use this when copying or printing on paper that cannot be loaded in
Trays 1 - 4, 6-7, such as heavyweight paper or other special media.
3 Tray 5 (Bypass) top cover Open this cover to clear paper jams.
4 Front cover for the High
Capacity Tray unit
This unit delivers paper fed through the Tray 6, Tray 7, or Tray 5
(Bypass) to the main unit. Open the front cover of this unit when
clearing paper jams.
5 Tray 6, 7 Load paper here. If you close the tray after loading paper, the tray
automatically adjusts the its front and rear positions based on the
center of the paper.
5
4
1
3
2
To Next Page
