318 7 Maintenance
5. Remove the new IBT belt cleaner from its
packaging, and insert it into the printer.
Important
• Never touch the film surface of the IBT belt cleaner
when installing it.
• Insert the IBT belt cleaner as far as it will go.
6. While pressing the knob, tighten it to secure
the IBT belt cleaner in place.
7. Rotate the IBT belt cleaner cover to the left
to close it.
8. Close the front cover.
Replacing the Odor Filter
1. Detach the Cover R10.
R10
To Next Page
