302 Using the Operator Panel Menus and Keypad
NOTE:
• This item is displayed when the Ethernet cable is disconnected and Wi-Fi is set to On.
Manual
Setup
Enter Network
(SSID)
Specify a name to identify the wireless network. Up to 32
alphanumeric characters can be entered.
Infrastructure Select to configure the wireless settings through the access point
such as a wireless router.
No Security Select to configure the wireless settings with no
encryption settings.
Mixed Mode
PSK
Select to configure the wireless settings with the
Mixed Mode PSK encryption. Mixed Mode PSK
automatically selects the encryption type from
either WPA-PSK-TKIP, WPA-PSK-AES, or WPA2-
PSK-AES.
PassPhrase
Entry
Specify the pass phrase of
alphanumeric characters from 8
to 63.
WPA-PSK-
TKIP
Select to configure the wireless settings with the
WPA-PSK-TKIP encryption.
PassPhrase
Entry
Specify the pass phrase of
alphanumeric characters from 8
to 63.
WPA2-PSK-
AES
Select to configure the wireless settings with the
WPA2-PSK-AES encryption.
PassPhrase
Entry
Specify the pass phrase of
alphanumeric characters from 8
to 63.
WEP Select to configure the wireless settings with the
WEP encryption.
WEP Key
Entry
Specify the WEP key to use
through the wireless network. For
64bit keys, enter 10 hexadecimal
characters. For 128bit keys, enter
26 hexadecimal characters.
Transmit
Key
Select a transmit key from WEP
Key 1, WEP Key 2, WEP Key 3,
and WEP Key 4.
Ad-hoc Select to configure the wireless setting without the access point such
as a wireless router.
No Security Select to configure the wireless settings with no
encryption settings.
WEP Select to configure the wireless settings with the
WEP encryption.
WEP Key
Entry
Specify the WEP key to use
through the wireless network. For
64bit keys, enter 10 hexadecimal
characters. For 128bit keys, enter
26 hexadecimal characters.
Transmit
Key
Select a transmit key from WEP
Key 1, WEP Key 2, WEP Key 3,
and
WEP Key 4.
To Next Page
