CHAPTER 2 PRIMEPOWER200 Pedestal Server
2.1 Overview
The following describes the key features and appearance of the PRIMEPOWER200 Pedestal Server.
Key Features
The server unit can be configured with up to two CPUs.
Up to 16 gigabytes of memory can be mounted.
Six PCI slots (2 x 33/66MHz + 4 x 33MHz) are provided.
Up to eight UltraSCSI disk drives can be built in.
One tape unit (DDS4 DAT, 8mm) can be installed.
A CD-ROM drive is provided as standard.
One 100Base-TX port, two serial ports (RS-232C) and one keyboard/mouse port are provided
as standard.
Appearance
The following illustration shows the appearance of the PRIMEPOWER200 Pedestal Server.
CHECK LED
(Amber)
POWER LED
(Green)
Lock
Stabilizing Feet
Figure 2.1 PRIMEPOWER200 Pedestal Server
4
