CHAPTER 2 PRIMEPOWER200 Pedestal Server
2.3.2 Installation specifications
The following table shows the installation specifications for the PRIMEPOWER200 Pedestal Server.
Table 2.2 Installation Specifications of the PRIMEPOWER200 Pedestal Server (1/2)
Item Specification
Weight 48 kg (105.96 lb.) (max.)
Power Supply
Voltage
Frequency 50/60 Hz (+2 ~ -4%)
Max. Current 5.0 A (100V)
Leak Current
Frame Resistance
Temperature Operating
Non-operating
Humidity Operating 20 ~ 80% RH (non-condensing)
Non-operating 8 ~ 80% RH (non-condensing)
Vibration Operating 0.2 G
Non-operating 0.4 G
Noise 47 db(A) (*2)
Form Factor Pedestal
2.5 A (240V)
Single phase
AC100 ~ 120V (
±
10%)
Single phase
AC200 ~ 240V (
±
10%)
²
3.5 mA
²
100Ω
5 ~ 35
û
C (+41 ~ +95 F) (*1)
0 ~ 50
û
C (+32 ~ +122 F)
*1: If the ambient temperature exceeds 35 deg. C (95 deg. F) during operation, a warning message is
displayed. Take steps to rectify the problem immediately.
*2: The indicated noise is the mean value of measurements obtained in a low-noise anechoic chamber.
The actual noise measured at the installation site may be greater than the indicated value due to
background noise and echoes.
