174
Chapter 7 Installing Internal Options
7.4.3 How to Install an Expansion Card
1 Turn off the power and remove the top cover.
ī"7.2 Removing and Attaching the Top Cover" (pg.164)
2 Touch a metal part of the server to discharge static electricity.
3 Unplug the cable from the SCSI or RAID card installed in Slot 1.
Unplug the SCSI cable and the hard disk access LED cable.
4 Loosen the screws on the rear side of the server, and remove the card locking
frame.
Hard disk access LED cable
SCSI cable
Card locking frame
Screw
Screw
To Next Page
