Fujitsu Primergy RX100 S2 User Manual

183
PRIMERGY RX100 S2 User’s Guide
7
Installing Internal Options
7.6.3 How to Install the Internal Hard Disk Unit
1 Turn off the power and remove the top cover.
"7.2 Removing and Attaching the Top Cover" (pg.164)
2 Touch a metal part of the server to discharge static electricity.
3 Disconnect the extension cables of the power cable from the server.
4 Connect the extension cable disconnected from the server in Step 3 to the
internal hard disk unit.
[Front]
Extension cable
Extension cable

Fujitsu Primergy RX100 S2 Specifications

General

Brand	Fujitsu
Model	Primergy RX100 S2
Category	Server
Language	English
