184
Chapter 7 Installing Internal Options
5 Remove the bay to accommodate an internal hard disk unit.
Loosen the screws (1) and slid the bay toward you to remove it (2).
6 Install the internal hard disk unit to the hard disk bay.
Fasten the bay to the internal hard disk unit using the screws supplied with the disk unit.
1
2
Hard disk bay
