266
Appendix
C.2 Connecting the Server to a PC
Connect the server to a PC using a cross cable.
ī In the BIOS Setup Utility, perform the following setting.
ā¢ On the [Peripheral Configuration] submenu of the [Advanced] menu, change [Serial Multiplexer] to
[BMC].
ī"8.2.6 Peripheral Configuration Submenu" (pg.200)
C.3 Operating the Remote Control Utility
The following explains how to operate the Remote Control Utility.
ā Connection
1 Connect the serial port connector 1 to the management terminal using an RS-
232C cross cable.
2 Establish connection using the terminal software.
ā Operation on the Server
Perform the following operation in the terminal software on the management terminal.
1 Establish connection using the terminal software and press the [Enter] key.
The following message appears.
Login>
Serial port
Server (Rear)
Personal computer
Cross cable
Serial port
To Next Page
