27
PRIMERGY RX100 S2 User’s Guide
1
Overview
l Floppy disk drive connector
m Power connector for CD-ROM drive
The power cable for the optional CD-ROM drive is plugged in.
n JP3 (Fixed)
o JP4 (Fixed)
p Card locking frame connector
An expansion card locking frame is installed.
q JP1
Used to clear the CMOS storage data. For more details, refer to "8.1 Jumper Pin Settings"
(pg.190).
To Next Page
