Preliminary steps
▶
"Shutting down the server" on page 45
.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 48.
▶
"Removing the front panel module" on page 269.
Removing the dummy cover
Figure 187: Removing the dummy cover
▶
Remove the dummy cover.
CAUTION
▶
Keep the dummy cover for future use.
▶
If you remove the front VGA board again and do not replace it with
a new one, the dummy cover must be reinstalled to comply with
EMC regulations and to satisfy cooling requirements and fire
protection measures.
Front panel
274 Upgrade and Maintenance Manual RX1330 M4
