Fujitsu PRIMERGY RX1330 M4 Upgrade And Maintenance Manual

Installing the new TPM
The TPM spacer is already present on the system board.
▶
Install the TPM, see "Installing the TPM" on page 296.
Concluding steps
▶
"Installing the air duct" on page
64.
▶
"Reassembling" on page 52.
▶
"Connecting the power cord" on page 56.
▶
"Switching on the server" on page 58.
▶
"Resuming BitLocker functionality" on page 86.
You can find information on configuring the TPM in the corresponding
BIOS Setup Utility reference manual.
15.5 iRMC microSD card
15.5.1
Note for embedded Lifecycle Management (eLCM)
The iRMC microSD card is necessary for using the embedded Lifecycle
Management (eLCM) functionality of the iRMC. It requires a valid eLCM
license key, which is always purchased together with the iRMC microSD
card and activated through the iRMC web interface.
For more information, see the “ServerV
iew embedded Lifecycle
Management (eLCM)” user guide.
15.5.2 Installing the iRMC microSD card
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
System board and components
RX1330 M4 Upgrade and Maintenance Manual 305

Fujitsu PRIMERGY RX1330 M4 Specifications

General

Chipset	Intel C246
Processor	Intel Pentium, Intel Celeron
Memory Type	DDR4
Memory	Up to 64 GB
Memory Slots	4 DIMM slots
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
Network	2x 1GbE onboard, optional additional NICs
Power Supply	450W
Form Factor	1U
RAID Controller	optional SAS RAID controller
