106 Maintenance Manual RX900 S1
Expansion cards and BBU
For information on the population order and the capability of the slots see
"Baseboard D3081, CPUMEMR D3131, PCIR D3082 for PRIMERGY
RX900 S1 Technical Manual".
I The RX900 S1 server can be equipped with one Modular RAID controller
and two SAS RAID controllers but only for two of these RAID controllers
a BBU can be installed.
Figure 52: PCIe slot assignment
