286 Maintenance Manual RX900 S1
Baseboard
14.6.11 Inserting the CPUMEMR guide
Figure 180: Inserting the CPUMEMR guide
Ê Insert the CPUMEMR guide in the installation slot (1).
Ê Fasten the captive screws of the CPUMEMR guide (2).
