RX900 S1
Maintenance Man
ual
93
Hard disk and solid state drives
6.4.6
Remo
ving the air guide
Figure 42: Removing the
air guide
Ê
Loosen the captive scre
ws (1).
Ê
Lift the air guide out of the chassis (2).
/
/
