RX900 S1 Maintenance Manual 315
Cables
15.4 Replacing power cables of the optical drive,
the SAS backplane, or the power
distribution board
15.4.1 Required tools
● Starting and completing the task:
– key for the rack doors (if applicable)
– Phillips Ph2 screw driver
● Replacing the power cables of the optical drive, the SAS backplane, or the
power distribution board:
– Phillips Ph2 screw driver
15.4.2 Starting the task
Ê Perform the following procedures:
1. "Opening the rack door" on page 40
2. "Locate the faulty server" on page 37
3. "Shutting down the server" on page 41
4. "Sliding the server out of the rack" on page 42
5. "Opening the server" on page 44
Authorized personnel
Authorized specialist personnel can carry out replacement tasks for
integral server components. Ask you local Fujitsu service center for
more detailed information.
V CAUTION!
Procedures indicated as "Authorized personnel only“ must be
done by Fujitsu service personnel or technicians trained by
Fujitsu for doing these tasks. Please note that unauthorized
interference with the system will void the warranty and exempt the
manufacturer from all liability.
