RX900 S1
Maintenance Man
ual
237
Front panel and ext
ernal connectors
12.2.4
Inser
ting the
fr
ont panel module
Figure 144: Inser
t
ing the front panel module
Ê
Slide the front panel module into the ba
y until it clic
ks into place (1).
Ê
Slide the video connector in the front panel module u
ntil it clic
ks into
place
(2).
