170 Maintenance Manual RX900 S1
Expansion cards and BBU
8.11.2 Starting the task
Ê Perform the following procedures:
1. "Opening the rack door" on page 40
2. "Shutting down the server" on page 41
3. "Sliding the server out of the rack" on page 42
4. "Removing the rear cover" on page 46
8.11.3 Connecting the BBU cable to the BBU
Figure 99: Connecting the BBU cable
Ê Connect the BBU cable to the battery.
I The cable can only be installed in one direction. Make sure that the
markings on the connector are aligned with the corresponding marking
on the socket.
