Fujitsu PRIMERGY RX900 S1 - Removing the Air Duct (if Applicable)

RX900 S1 Maintenance Manual 185
Main memory
Figure 106: CPUMEMR slot assignment
9.1.5 Removing the air duct (if applicable)
Figure 107: Removing an air duct
Ê Press the green buttons (1).
Ê Lift the handles (2) to disconnect the air duct from the baseboard.
Ê Carefully pull the air duct up and out (3).
/
2
1
4
0
6
3
5
/
0
/
0
1
