162 Maintenance Manual RX900 S1
Expansion cards and BBU
8.9.6 Installing the PCI Riser (if applicable)
Figure 93: Installing the PCI Riser
Ê Carefully insert the PCIR in the slot (1).
Ê Lock the PCIR by pushing down the handle (2).
8.9.7 Completing the task
Ê Perform the following procedures to complete the task:
1. "Installing the rear cover" on page 48
2. "Mounting the server in the rack" on page 49
3. "Bringing the server back to operation" on page 51
4. "Closing the rack door" on page 51
