RX900 S1 Maintenance Manual 159
Expansion cards and BBU
8.9.2 Starting the task
Ê Perform the following procedures:
1. "Opening the rack door" on page 40
2. "Locate the faulty server" on page 37
3. "Shutting down the server" on page 41
4. "Sliding the server out of the rack" on page 42
5. "Removing the rear cover" on page 46
6. "Locate the faulty component by PRIMERGY diagnostics indicators" on
page 39
7. If applicable: "Mounting expansion card slot brackets" on page 107
8. If applicable: "Preparing the SFP+ transceiver module" on page 115
8.9.3 Removing the PCI Riser (if applicable)
Figure 90: Removing the PCI Riser
0
1
/
