166
Maintenance Manual
RX900
S1
Ex
pans
io
n car
ds an
d BBU
8.10.5
Inser
ting the Modular RAID controller
Figure 96: Connecting the SAS cables
Ê
Connect the SAS cab
les to the Modular RAID controller por
ts as f
ollows:
–
MLC1 por
t (A): HDD/SSD modules #0, #1, #2, #3
–
MLC2 por
t (B): HDD/SSD modules #4, #5, #6, #7
C
A
C
B
165
167
