02TX150S2108 July 2004 U41057-J19-Z146-1-76
System board Removal/installation routines
Main memory
There are four slots for main memory. You can install 256 Mbyte, 512 Mbyte and
1 Gbyte DDR DIMM memory modules. The board supports a maximum of
4 Gbytes. Memory modules with different memory capacities can be combined.
You may only use unbuffered 3.3 V memory modules. Buffered memory
modules are not allowed and lead to a device failure. DDR DIMM
memory modules may meet the PC2100/2700/3200 specification.
The following memory configurations are possible:
In the dual-channel configuration you must install identical memory
modules in DIMM 0A and 0B (blue slots) and identical memory modules
in DIMM 1A and 1B (black slots).
Mode DIMM 0A
(blue)
DIMM 1A
(black)
DIMM 0B
(blue)
DIMM 1B
(black)
1x memory module
S26361-F3019-E51x
(single-channel)
populated
2x memory module
S26361-F3019-E51x
(single-channel)
populated populated
3x memory module
S26361-F3019-E51x
(single-channel)
populated populated populated
4x memory module
S26361-F3019-E51x
(single-channel)
populated populated populated populated
1x memory
S26361-F3019-E52x
(dual-channel)
populated populated
1x memory
S26361-F3019-E52x
(dual-channel)
populated populated
2x memory
S26361-F3019-E52x
(dual-channel)
populated populated populated populated
!
!
