Opening/closing the server Removal/installation routines
Opening/closing the server
Floorstand model
If you want to fully open the server you must proceed as follows:
– remove the drive covers
– remove the left side cover
– remove the front cover
Removing/installing the drive covers
There are two drive covers:
– hard disk cover
– cover of the accessible drives (front sliding cover upper position)
Hard disk cover
1
2
4
3
