Fujitsu PRIMERGY TX150 S2 User Manual

02–TX150S2–120 July 2004 U41057-J19-Z146-1-76
Power supply Removal/installation routines
Power supply
The server can be equipped with a standard power supply or with a redundant
power supply. In the basic configuration, the server is equipped with the
standard power supply unit.
Standard power supply
Replacing standard power supply unit
Requirements
– server has been switched off
– power cords have been disconnected
– left side cover has been removed
You can replace the power supply without removing the adapter sheet.
Ê Disconnect all cables of the power supply.
Take note of the cabling.
Ê Remove the four mounting screws of the power supply at the rear (1).
i
i
1
