Removal/installation routines System board
© Siemens Nixdorf Informationssysteme AG 1995 Pfad: P:\02-systemeinheiten\TX150S2\TX150S2-e\TX150S2-e.k04
Changing the system board
Removing the system board
Requirements
– server has been switched off
– power cords have been disconnected
– left side cover has been removed
Ê Lay the floorstand model on a flat surface with the uncovered side facing
upwards.
This step has to be carried out by two people as the server may
weight up to 28 kg.
Ê Remove the memory modules.
Ê Remove all controllers from their slots.
Ê Remove the air duct.
Ê Remove the system fan.
Ê Remove the processor heat sink.
Ê Remove the processor.
Ê Remove all cables which may be connected to the system board.
Take note of the slots of the controllers and the cabling.
!
