Accessible drives and operating panel Removal/installation routines
Accessible drives and operating panel
A total of three accessible drives and a floppy disk drive can be mounted in the
PRIMERGY TX150S2 server.
Each SCSI drive must be assigned to a unique SCSI ID (4-6). The termi-
nation has to be switched off.
In the SCSI version the two lower 5.25 inch bays for accessible drives can be
used to install a HDD extension box. But it is required that the server is equipped
with a 1- or 2-channel RAID controller.
It is not allowed to operate the hard disks of the HDD extension box
together with the internal hard disks via one common SCSI line.
You find the operating panel module also in the drive cage for accessible drives.
Installing/removing an accessible 5.25" drive
Requirements
– server has been switched off
– power cords have been disconnected
– left side cover has been removed
– front cover has been removed
New 5.25"drive are delivered without EasyClick rails. Before installing a
new 5.25"drive you have to unscrew the EasyClick rails from the dummy
cover or the old 5.25"drive. Afterwards the EasyClick rails have to be
mounted on the new 5.25"drive.
If a 5.25"drive is to be installed in a bay in which no 5.25"drive was previously
installed, then the dummy cover must be removed from this bay beforehand.
In case the 5.25"drive is removed and not replaced by a new one, the dummy
cover has to be reinstalled to comply with applicable EMC regulations (regula-
tions on electromagnetic compatibility) and satisfy cooling requirements and fire
protection measures.
