Fujitsu PRIMERGY TX150 S2 - Rack Model

U41057-J19-Z146-1-76 July 2004 02–TX150S2–81
Removal/installation routines Opening/closing the server
© Siemens Nixdorf Informationssysteme AG 1995 Pfad: P:\02-systemeinheiten\TX150S2\TX150S2-e\TX150S2-e.k04
Rack model
Ê Loosen the four knurled screws (1) and pull the server carefully out of the
rack up to the stop (2).
Ê Press in the locking spring (1) on both sides and carefully pull the server
outwards (2).
1
2
1
2
