U41057-J19-Z146-1-76 July 2004 02–TX150S2–47
Installation and initial operation Settings
© Siemens Nixdorf Informationssysteme AG 1995 Pfad: P:\02-systemeinheiten\TX150S2\TX150S2-e\TX150S2-e.k02
ISA bus resources
"IRQ" = interrupt assigned as shipped
"Address" = this address can be used for your particular device
"Address" = this DMA can be used for your particular device
Default settings are shown in bold print.
PCI bus resources
PCI slots
Device IRQ Address DMA
Keyboard 1 060, 064
Serial port COM2 3 03F8, 02F8, 03E8, 02E8
Serial port COM1 4 03F8, 02F8, 03E8, 02E8
5
Floppy disk drive controller 6 03F0-3F5, 3F7 2
Parallel port LPT1 7 0278, 0378, 03BC 0, 1, 3
Real-time clock (RTC) 8 070-071
free 9, 10, 11
Mouse controller 12
Numeric processor 13 0F0-0FE
IDE controller 14 1F0-1F7
free 15
PCI slot 64 bit/
32 bit
Bus frequency Description
1 32 bit 33 MHz / 5 V 32 bit PCI bus slot
2 64 bit 66 MHz / 3.3 V 64 bit PCI bus slot
3 64 bit 66 MHz / 3.3 V 64 bit PCI bus slot
4 32 bit 33 MHz / 5 V 32 bit PCI bus slot
5 32 bit 33 MHz / 5 V 32 bit PCI bus slot
