Fujitsu PRIMERGY TX150 S2 User Manual

U41057-J19-Z146-1-76 July 2004 02–TX150S2–49
Installation and initial operation Settings
© Siemens Nixdorf Informationssysteme AG 1995 Pfad: P:\02-systemeinheiten\TX150S2\TX150S2-e\TX150S2-e.k02
A...D = Interrupt output of the PCI controller
* : Interrupts of SCSI channel A respektive B
** : LAN interrupts are not PCI-specific
*** : onboard SATA controller, if installed
A B C D E F G H PXIRQ0 PXIRQ1 PXIRQ2 PXIRQ3
Slot 1 ABCD---- - - - -
Slot 2 -------- C D A B
Slot 3 -------- B C D A
Slot 4 DABC---- - - - -
Slot 5 CDAB---- - - - -
USB
controller
HC0
A------- - - - -
USB
controller
HC1
---A---- - - - -
USB 2.0
controller
-------A - - - -
LAN
controller **
--A----- - - - -
VGA
controller
----A--- - - - -
Promise
controller ***
-------- - A - -
SCSI
controller
-------- A - - -
IDE
controller
(P-ATA)
A
Serial ATA
controller
A
