How to Load Documents
33
How to Load Documents
Load documents in the ScanSnap in the following procedure.
For details about documents that can be loaded, refer to "Documents for Scanning" (page 31).
1. If you are loading multiple sheets, check the number of sheets.
The maximum number of sheets in the ScanSnap is as follows:
For A4 or smaller sizes: Up to 10 sheets can be loaded (with paper weight of 80 g/m²
[20 lb] and thickness of the document stack under 1 mm).
2. Fan the documents.
1. Hold both ends of the documents and fan them a few times.
2. Rotate the documents by 90 degrees and fan them in the same manner.
3. Straighten the edges of the documents and slightly displace the top
edges at an angle.
ATTENTION
If you try to scan more than the maximum amount that can be loaded, the following problems may
occur:
z Files may not be properly created due to excessive file size.
z Paper jams may occur.
ATTENTION
Paper jams or damage to documents may occur if you scan the documents without aligning the
edges first.
Back
Back
at an angle
Feed direction

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Fujitsu Scan Snap S1300i and is the answer not in the manual?

Fujitsu Scan Snap S1300i Specifications

General IconGeneral
Optical Resolution600 dpi
ADF Capacity10 sheets
InterfaceUSB 2.0
Color Depth24-bit
Duplex ScanningYes
Scanning MethodCIS (Contact Image Sensor)
Scanner TypeSheetfed
Max Document SizeA4
Scan Speed12 ppm (simplex), 24 ipm (duplex)
Dimensions284 x 99 x 77 mm
Weight1.4 kg
Supported Operating SystemsWindows, macOS
Power SourceUSB Bus Power
