Installation Specifications
485
Installation Specifications
The following table summarizes the installation specifications of the ScanSnap.
Item Specification
Outer dimensions (Width × Depth × Height) Minimum: 284 × 99 × 77 (mm) / 11.2 × 3.9 × 3.1 (in.)
(when the ADF paper chute (cover) is closed)
Maximum: 284 × 231 × 240 (mm) / 11.2 × 9.1 × 9.4 (in.)
(when the ADF paper chute cover is open and the
extension is extended)
Weight 1.4 kg (approx. 3.09 lb)
Input power Voltage Power cable
connection
100 to 240 V
USB bus power
cable connection
5 V (the computer must have two USB ports: one for
power connection and one for USB cable connection)
Phase Single phase
Frequency range 50/60 Hz
Power consumption Power cable
connection
During operation: 9.0 W or less
During standby: 3.2 W or less
USB bus power
cable connection
During operation: 5.0 W or less
During standby: 2.0 W or less
Temperature/
humidity
allowable
ranges
Temperature During operation: 5 to 35°C / 41 to 95°F
During standby: -20 to 60°C / -4 to 140°F
During storage/transportation: -20 to 60°C / -4 to 140°F
Humidity During operation: 20 to 80%
During standby: 8 to 95%
During storage/transportation: 8 to 95%
284 mm (11.2 in.) 231 mm (9.1 in.)
240 mm
(9.4 in.)
To Next Page
