5.1 WAN Settings
5-1
5.1 WAN Settings
5.1.1 Overview
You will make the settings for Standard IP data and Streaming IP data in this chapter.
The settings will be made via; Setting -> Network settings -> WAN, and they are for the
service types, application types, connection passwords, information from the provider
(connection IP, DNS Server IP, etc.), and Network connection/disconnection conditions.
The default value allows the user to use Standard IP data only.
Data communication connection and disconnection operations will be executed via the
screens shown below.
x FELCOM-250/500 Web MMI : Main -> Data connection
x FELCOM-250/500 Web MMI : Settings -> Network setting -> WAN
x Handset : Web -> 5 Std. IP
Standard IP data is the only service available from the Handset, and you
cannot initiate the connection for Streaming IP data.
Note)
1. Note that you may be restricted for connecting with Streaming IP data depending
onto the contract with the provider. Furthermore, you may be subject for
communication restriction such as being unable to connect with the Internet.
It is recommended that you execute the commissioning test with an SIM card
which is allowed to execute all service when implementing the test.
2. You can connect with several different services concurrently. The table shown
below describes the actual combination of services concurrently available.
Reference only
Streaming IP
32 k 64 k 128 k 256 k
432 k Standard IP Connection
3 3 3
OK
3 3 3
3
OK
3
3
OK
3
3 3
OK
x Several connections can be established for the same service (8 to 256 k) for
Streaming IP data.
x Several connections cannot be established for the same application at the same
time.
For example, if you connect with Standard IP data (Primary), and then try to
connect with the Browser by 32 k Streaming (Secondly) and by 64 k Streaming
(Secondly), the following message will be displayed; “Can't connect. The
connection for same application has already been connected”.
Chapter 5. WAN Settings
