9.1 Communication Unit: FB-2000
Fig. 9.1.1 Front panel
Fig. 9.1.2 Rear panel
Chapter 9. Parts Location
Power switch
Power: Light turned on when
power is turned on
READY: Light turned on during
ANT tracking status and
when network registration
has successfully completed
STATUS 1-4
Normally all
lights turned on
SIM card slot
- Light off: Satellite search
in process
- Light blinking: Satellite signal detected
TX: Light turned on while signal is Transmitted
Analog (RJ-11) x 2
Cable retainment tag
Power input: 12-24 VDC
GND
LAN x 4
NMEA
Alarm
Antenna terminal
L-BAND OUT
RS-232C
Analog x 2
Analog (RJ-11) x 2
Cable fixture
