10.3 System information
10-15
10.3.4 ATB information
The display is made based on the information for ATB: Antenna Tracking Board.
1. Hardware type
FELCOM-500: AS02204-0x FELCOM-250: AS1406-0x
The type of ATB Module is displayed.
2. Hardware version
The Rev. number of the ATB Module is displayed.
3. Software version
The software number of the ATB Module is displayed.
4. Product data
The date of manufacture of the ATB Module is displayed in 4 bytes.
5. Serial No.
The serial number of the ATB is displayed.
FELCOM-500 Antenna: FB-1500
FELCOM-250 Antenna: FB-1250
ATB: AS02204-0x
LNA: AS01406-0x
HPA: AS02202-0x
LNA: AS01406 Rev.2 ATB: AS01804 Rev.1 HPA: AS02202 Rev.1
