 7.1 LAN IP address
7-10
7.1.3 Routing
This setting should be implemented by the administrator. The outline of the
procedure will be described here.
This is the setting for when the Router is connected to the communication unit, and
when a different network is newly established.
Settings can be made for up to 20 network cases. If you click Add routing, the settings
screen shown below will be displayed.

The network address for the communication
unit is 192.168.1.0.
The description shown below assumes the
network address configured by the Router as
172.16.0.0.
Note)
Set a Static IP address for the IP address
for the system connected to the Router.
