9.5 Antenna Unit: FB-1250
9-30
Cross EL motor belt
tension adjusting screw x 4
Fig. 9.5.16 Adjusting cross EL motor belt tension
Fig. 9.5.17 Adjusting AZ motor belt tension
Radome base
attachment screw x 2
Cross EL motor belt
tension adjusting screw x 4
