9. INSTALLATION
9-6
9.5 Input/Output Data
This equipment inputs/outputs NMEA0183 data shown below. Note that NMEA0183
version (1.5/2.0/3.0) can be a selected from the I/O setup screen.
NMEA0183 Input Sentence
NMEA0183 Output Sentence
Other output sentences:
REM1/REM2: Output data to radar, echo sounder and so on.
AP: Mainly output data to an autopilot.
GPS: Mainly output GPS satellite information for serviceman.
*: Not output when no waypoint is set.
**: Talker; GP
Talker Format Note
GP RTE
PFEC, GPwp1
PFEC, GPrtc
PFEC, GPxfr
PFEC, cprst
SD TLL Request for Target
PFEC, SDmrk Mark
Additional information of longitude, latitude and its position.
Format** REM1 REM2 AP GPS
AAM* ON
APB* ON
BOD* ON
BWC* ON ON
BWR* ON ON
DTM ON ON
GGA ON ON ON
GLL ON ON
GSA ON
GSV ON
RMB* ON ON
RMC ON ON
VTG ON ON ON ON
XTE ON
ZDA ON ON ON
