Furuno RC-1800T - Rc-1800 T (150;250 W)

1.1 System configuration
1-3
1.1.3 RC-1800T (150/250W)
NBDP Terminal
DP-6 & IB-581
Distress Alert
Unit IC-302
Received Call
Unit IC-303
Inmarsat-C
Antenna Unit
IC-112
AC/DC Power Supply
Unit PR-850A
AC/DC Power Supply Unit
PR-300
Battery Charger
BC-6158/6200
Power Amp Unit
PA-2500
(For FS-1562-25)
Fuse Box
SB-180
Printer
PP-510
Printer
PP-510
DSC Terminal
DSC-60
Inmarsat-C
IC-212 & IB-581
Antenna Coupler
AT-1560-25
(for RC-1800T-25E)
AT-1560-15
(for RC-1800T-15E)
SSB Radiotelephone
FS-1562-25 (250 W) OR
FS-1562-15 (150 W)
Preamp
FAX-5
Whip Antenna
04S4176
Distress Alert
Unit IC-302
Battery 24 VDC
SSB Antenna
Stepdown Transformer
PT-3000
100/110/220 VAC, 1
φ , 50/60 Hz
220/440 VAC, 3
φ , 50/60 Hz
(For 220/440 VAC, 3 φ
to 100VAC)
(For DSC WR)
Printer I/F
IF-8500
Fig.1.1.3 RC-1800T(150/250W)
