3.3 RC-1800F/T(250W)
3-9
3.3 RC-1800F/T (250W)
DSC-60
FS-1562
(FS-2550)
Battery control panel
Unscrew the two screws
and pull out the transceiver.
IC-212 power switch DP-6 power switch
Fig. 3.3.1 TR (MF/HF Radio telephone)
Cooling fan for RT
: 109P0612H702
Fig. 3.3.2 Cooling fan
Code No.
00013043200
