Furuno RC-1800T Service Manual

1.1 System configuration
1-1
1.1 System configuration
1.1.1 RC-1800F (150/250W)
Printer
PP-510
Antenna Coupler
AT-1560-25
(for RC-1800T-25E)
AT-1560-15
(for RC-1800T-15E)
Inmarsat-C
Antenna Unit
IC-112
Printer
PP-510
DSC Terminal
DSC-60
SSB Radiotelephone
FS-1562-25 (250 W) OR
FS-1562-15 (150 W)
NBDP Terminal
DP-6 & IB-581
Power Amp Unit
PA-2500 (FS-1562-25)
Inmarsat-C
IC212 & IB-581
AC/DC Power
Supply Unit
PR-850AR
AC/DC Power
Supply Unit
PR-300
Battery Charger
BC-6158
(For MOL Spec.
BC-6153A)
Distress Alert
Unit IC-302
Received Call
Unit IC-303
Preamp
FAX-5
Whip Antenna
04S4176
Distress Alert
Unit IC-302
100/110/220 VAC, 1 φ , 50/60 Hz
220/440 VAC, 3
φ , 50/60 Hz
Battery 24 VDC
SSB Antenna
Stepdown transformer
PT-3000
(For DSC WR)
Printer I/F
IF-8500
(For 220/440 VAC 3 φ ,
to 100VAC)
Fig.1.1.1 RC-1800F(150/250W)
Chapter 1 Configuration
