Home screen
Menu screen Accessory menu screen Timer
133
Function
Timer
Timer selection
First, select the type of timer
at the "Mode" item. The setup
screen varies depending on the
type of timer. This figure shows
the Up timer setup screen.
-Up timer
-Fuel down timer
-Lap timer
-Lap navigate timer
Time display
Minute display (min)
Second display (sec)
1/100-second display
(Preparation)
Assign the "Timer start" switch using the Switch select func-
tion (page 71). When resetting by the switch, assign "Timer
reset" also.
1
(Racing timer type selection)
Tap the "Mode". The mode list appears on
the "Timer" menu screen, and tap the rac-
ing timer type.
Up timer
Fuel down timer
Lap timer
Lap navigate timer
2
When finished, return to the Accessory menu screen by pressing the HOME button.
Racing timer type selection
Setting type
- Tap to select
