Home screen
Menu screen
Menu-1 Menu-2
Calibration
System menu screen
191
Function
Calibration
6WHHULQJDQGWKURWWOHFRUUHFWLRQFDQEHDSSOLHG8VHWKLVIXQFWLRQZKHQDPHFKDQLFDOR൵VHW
has occurred for some reason.
Calibration
+RZHYHULIFRUUHFWLRQZDVDSSOLHGLWPD\EHQHFHVVDU\WRUHFKHFNWKHVHWYDOXHVRIDOO
the setup functions.
(Preparation)
Tap the [Wheel]. The neutral correction screen appears.
1
(Steering neutral adjustment)
At neutral, turn the steering wheel left and right. Press the
[Neutral] button while the steering wheel is in its neutral posi-
tion. If the [Neutral] position is OK, the [End Point] button will
appear after pressing the [Neutral] button. If not within the
correction range, the [End Point] button will not appear.
2
(Steering wheel travel adjustment)
With [End Point], slowly rotate the steering wheel left and
right, tap the [End Point] button. If the [End Point] correction
is OK, the display will return to the calibration screen. If the
end point is not within the correction range, the display does
not return to the calibration screen. In this case, return to the
system menu screen by pressing the HOME button. If the
operation cannot usually be ended even when correction is
repeated, please contact the Futaba Service Center.
Steering adjustment
3
When finished, return to the System menu screen by pressing the HOME button.
To Next Page
