Home screen
Menu screen
Menu-2
Menu-1
Linkage menu
Channel limiter
For the S-FHSS (analog) system,
channels 5, 6, and 7 are displayed
on the 2nd page.
Tap to change page.
76
Function
Channel Limiter
Channel Limiter
The channel limiter function limits the maximum servo movement. By superimposing mix-
ing, the linkage can be protected by setting the limiter in case servo motion becomes unex-
pectedly large.
(Preparation)
- Tap the travel button of the channel you want to set. Value input
buttons appear on the screen.
1
Use the [+] or [-] buttons to adjust the servo
angle.
Channel limiter adjustment
2
When finished, return to the Linkage menu screen by pressing the HOME button.
Adjust button
Adjust with the [+] and [-] but-
tons.
- Return to the initial value by
tapping the [reset] buttons.
Limiter rate
0~145
Initial value: 145
