FUTABA 7PXR - Servo View

Home screen
Menu screen
Menu-2
Menu-1
Linkage menu
Servo view
For the S-FHSS (analog) system, channels
5, 6, and 7 are displayed on the 2nd page.
66
Function
Servo View
The servo operation of each channel can be checked. Process of the steering angle adjust-
PHQWZKHQDPL[LQJIXQFWLRQZDVVHWHWFFDQHDVLO\FRQ¿UPLW
Servo View
1
Operating each channel, such as a steering wheel or throttle trigger, the graph moves, and
the servo operation can be confirmed.
2
When finished, return to the Linkage menu screen by pressing the HOME button.
Confirm operation
