No signal reception Red: On
Receiving signals Green: On
Receiving signals, but ID is unmatched. Green: Blink
*1
(T-FHSS, Red: On)
Unrecoverable failure (EEPROM,etc.) LED: Red and Green turn on alternately
/('FRXOGEHFKDQJHGWRUHGGXULQJLQWHUPLWWHQWO\GXULQJGDWDSURFHVVLQJ
40
Initial Set-Up
*
The T7PXR and T-FHSS SR receiver (R334SBS)/T-FHSS receiver (R304SB, etc.) memo-
rize the IDs linked last at each model memory. Since only one receiver ID is memorized at
each model memory, multiple T-FHSS SR/T-FHSS receivers cannot be used with the same
model memory. When a receiver at the same model memory is changed, re-linking is nec-
essary even if the receiver is already linked with the transmitter.
*
When using multiple T-FHSS SR/T-FHSS receivers, link each receiver with each T7PXR
model memory.
However, one receiver can be linked with multiple model memories. The telemetry function
communication status can be checked at the T7PXR home screen.
S-FHSS/FASST Receiver Link
1
Bring the transmitter and the receiver close to each other,
within 20 inches (half meter).
2
Turn on the power switch (PWR). On the display (DSP) side,
you cannot link.
3
Turn on the receiver.
4
Push the push switch of the receiver.
When the link is complete, the LED in the receiver changes to solid green. Check the opera-
tion of the servo.
Precaution:
If there are many Futaba 2.4GHz systems turned on close to your receiver might not link to your transmitter. In this
case, even if the receiver’s LED stays solid green, unfortunately, the receiver might have established a link to one
of the other transmitters. It is dangerous if you do not notice this situation. To avoid problems, it is strongly recom-
mended that you double-check that the transmitter controls the receiver by making the wheel or trigger inputs and
checking the servo response.
*Please refer to the table below for LED status vs receiver's condition.
LED status vs receiver’s condition:
