FUTABA 7PXR User Manual

192
Function
Calibration
(Preparation)
Tap the [Trigger]. The neutral correction screen appears.
1
(Throttle neutral adjustment)
At neutral, pull the throttle trigger to full throttle and the brake
position. Press the [Neutral] button while the trigger is in its
neutral position. If the neutral position is OK, the [End Point]
button will appear after pressing the [Neutral] button. If not
within the correction range, the [End Point] button will not ap-
pear. If not within the correction range, the end point correc-
tion screen will not appear.
2
(Throttle trigger travel adjustment)
With [End Point], pull the throttle trigger to full throttle and back
for braking, tap the [End Point] button. If the [End Point] cor-
rection is OK, the display will return to the calibration screen.
If not within the correction range, the display will not return to
the calibration screen. In this case, return to the system menu
by pressing the HOME button. When operation cannot usually
be ended even when correction is repeated, and cannot be
ended usually, contact the Futaba Service Center.
Throttle adjustment
3
When finished, return to the System menu screen by pressing the HOME button.

FUTABA 7PXR Specifications

General

Model	7PXR
Category	Remote Control
Channels	7
Frequency	2.4GHz
Telemetry	Yes
Model Memory	40
Display	Color LCD
Battery	6.6V
Compatibility	S-FHSS
Receiver	R334SBS
